Product Description:
As a Multi-function desktop jammer, this Adjustable 8 Antennas 2G 3G 4G Jammer GPS WIFI VHF UHF Blocker can block 8 frequency bands. Such as all cell phone signals: GSM/CDMA, 3G, 4G. It can also block GPS,WIFI and other signals Like VHF UHF RF 315 /433/868 MHZ Signals.
Basic Specifications:
Jam Signal Type：
1: JAM-880-LG: Full Bands Mobile Phone 4G/3G/2G +WiFi2.4G+ GPSL1+LOJACK
2: JAM-880-WG: Full Bands Mobile Phone 4G/3G/2G +WiFi2.4G+ GPSL1+GPSL2L5+Spy Cam
3:JAM-880-UV:Full Bands Mobile Phone 4G/3G/2G+WiFi2.4G+ GPSL1 L2 L5+LOJACK+Walkie-Talkie UHF VHF+RC433 315
Output Power：Total 18W，1-3W each band
Jam Radius：20-40meters
Power Supply：AC110-240V to DC12V
Cooling System：High efficiency aluminum alloy radiator, Build-in 3 cooling fan
Working Time：Not-stop Working
Product Size：370x 140x51 mm（not Include Antenna）
Product Weight: appr.3.5kg
Package Contents：Jammer Host x 1, AC adapter x 1,antenna x8,Car storage battery cable x1
Advantages:
★High output power, Total up to: 18W , jamming up to 40m (Still depends on the strength signal in given area)
★With Car storage battery Charger DC12V can be used in car
★External Omni-directional antennas all the TX frequency covered down link only
★Built-in good cooling system inside three fans, Working non-stopped
★Can adjust or turn off any single band without influencing the other bands operation
| Key Technical specifications : JAM-880-LG | |||
| Channel | Output port | Frequency range | Average out-putting power |
| 1 | LoJack | 167-175MHz | 35dBm/3W |
| 2 | CDMA or GSM | 851-894 or 925-960MHz | 35dBm/3W |
| 3 | DCS or PCS | 1805-1880 or 1920-1990MHz | 33dBm/2W |
| 4 | 3G | 2110-2170MHz | 33dBm/2W |
| 5 | 4G1 LTE | 700-803 or 790-862MHz | 35dBm/3W |
| 6 | 4G Wimax | 2500-2690 or 2300-2400MHz | 30dBm/1W |
| 7 | GPSL1 | 1570-1580MHz | 33dBm/2W |
| 8 | Wi-Fi 2.4G | 2400-2500MHz | 30dBm/1W |
| Power supply: AC adapter 50 to 60Hz, (110-240V AC-12V DC) Car storage battery Charger DC12V | |||
| Dimensions: (length ,width, height) 370x 140x 51mm（not Include Antenna） | |||
| Packing size: 47*27*13cm Net weight: 3kg Gross weight: 3.5kg | |||
|
Total power:18W Shielding radius: (20-40) meters At -75dBm Still depends on the strength signal in given area, Shielding radius of VHF/UHF signal about 10meters |
|||
| Warranty: one year from delivery date | |||
| Key Technical specifications : JAM-880-WG | |||
| Channel | Output port | Frequency range | Average out-putting power |
| 1 | CDMA or GSM | 851-894 or 925-960MHz | 35dBm/3W |
| 2 | DCS or PCS | 1805-1880 or 1920-1990MHz | 33dBm/2W |
| 3 | 3G | 2110-2170MHz | 33dBm/2W |
| 4 | 4G1 LTE | 700-803 or 790-862MHz | 35dBm/3W |
| 5 | 4G Wimax | 2500-2690 or 2300-2400MHz | 30dBm/1W |
| 6 | WIFI2.4G | 2400-2500MHz | 35dBm/3W |
| 7 | GPSL1 | 1570-1580MHz | 33dBm/2W |
| 8 | GPSL2+L5&Spy Camera | 1170-1280MHz | 33dBm/2W |
| Power supply: AC adapter 50 to 60Hz, (110-240V AC-12V DC) Car storage battery Charger DC12V | |||
| Dimensions: (length ,width, height) 370x 140x 51mm（not Include Antenna） | |||
| Packing size: 47*27*13cm Net weight: 3kg Gross weight: 3.5kg | |||
|
Total power:18W Shielding radius: (20-40) meters At -75dBm Still depends on the strength signal in given area, Shielding radius of VHF/UHF signal about 10meters |
|||
| Warranty: one year from delivery date | |||
| Key Technical specifications : JAM-880-UV | |||
| Channel | Output port | Frequency range | Average out-putting power |
| 1 | CDMA or GSM | 851-894 or 925-960MHz | 35dBm/3W |
| 2 | DCS or PCS | 1805-1880 or 1920-1990MHz | 33dBm/2W |
| 3 | 3G | 2110-2170MHz | 33dBm/2W |
| 4 | 4G1 LTE | 700-803 or 790-862MHz | 35dBm/3W |
| 5 | 4G Wimax | 2500-2690 or 2300-2400MHz | 30dBm/1W |
| 6 | RC315 | 315MHz | 35dBm/3W |
| 7 | VHF&LOJACK | 135-174MHz | 35dBm/3W |
| 8 | UHF&CDMA450&RC433 | 400-470MHz | 35dBm/3W |
| Power supply: AC adapter 50 to 60Hz, (110-240V AC-12V DC) Car storage battery Charger DC12V | |||
| Dimensions: (length ,width, height) 370x 140x 51mm（not Include Antenna） | |||
| Packing size: 47*27*13cm Net weight: 3kg Gross weight: 3.5kg | |||
|
Total power:18W Shielding radius: (20-40) meters At -75dBm Still depends on the strength signal in given area, Shielding radius of VHF/UHF signal about 10meters |
|||
| Warranty: one year from delivery date | |||
OEM Customized service
Customized for special frequency band , Wi-Fi5.8G 3.6GHz, etc
Silkscreen OEM service can be offered
Applications:
o It can be applied at meeting rooms, conference rooms, museums, galleries, theatres, concert halls, churches, temples, restaurants, classrooms, training centers, factories, banks, trains, bus and morePlaces that require silence, confidentiality and information security
o For some locations of special purpose such as hospitals, gas stations and more, please do field test first to make sure no interference happened to the normal operation of their equipment and instrument
