16g Auto Collar & Cuff Knitting Machine
$2800.00 /piece
Product Details
Transaction Comments
Basic Info
- Model NO.: SHD-838F1
- Knitting Machine Cut: E14
- Knitting Style: Flat
- Needle Style: Compound Needle
- Computerized: Computerized
- Condition: New
- Gauge: 7g, 8g, 9g, 10g, 12g, 14G 16g
- Power Supply: AC220V+-8% 50Hz
- Control System: Contorled Bycomputer System, LCD Display
- Plus Needle System: Electronic-Magnet Plus Needle
- Tension System: Electronic -Magnet
- Specification: CE; ISO
- Type: Flat
- Knitting Product Type: Collar
- Knitting Method: Single
- Needle Bar Style: Flatbed Knitting Machine
- Certification: CE, ISO9001: 2000
- Knitting Width: 52" 60"80"
- Knitting Speed: Maximum Speed 1.2m/S
- Driving System: in Phase Belt to and Fro Running
- Program Memory: Computer U Disk 2g
- Cam Control System: Electronic -Magnet
- Transport Package: Wooden Case
- Origin: Jiangsu China
Product Description
Generation 3 Auto Collar knitting Machine
Model No: SHD-838F1 Auto collar & Cuff flat knitting machine With 16g*52" needle bed
Features:
(1) Compact carriage and carriage fast return, make output more and more
(2) High & low butt needle with select butt , semi jacquard and more pattern available
(3) 2*3 yarn feeder on 3 rail guide,
(4) Motor Stitch 1-99 segment adjustable provides more options , linking become easy
(5) Multi-Gauge Cam system, Range from 5G-14G, only need change the complete needle bed, easy and friendly operating
(6) Fully safety protect with front and back cover, anti-dust and protect the operator
(7) Fine Stitch quality and Stitch no changes even Voltage Shrinking, Even stitch quality from start needle to End needle for each course
Specification:
Compact carriage with Multi-Gauge Cam System
Stably & Even stitch quality control by motor
6 Yarn feeder on 3 rail guide
Carriage Instant stop Or Return
Friendly Control And Program panel
Fully Operating and Max. 8 pattern In Memory
Knit can start from any Courses
Alarm In case of Error & information displayed
Pieces Counter, test function and more available
Apply for Plain & Semi Jacquard pattern
Model No: SHD-838F1 Auto collar & Cuff flat knitting machine With 16g*52" needle bed
Features:
(1) Compact carriage and carriage fast return, make output more and more
(2) High & low butt needle with select butt , semi jacquard and more pattern available
(3) 2*3 yarn feeder on 3 rail guide,
(4) Motor Stitch 1-99 segment adjustable provides more options , linking become easy
(5) Multi-Gauge Cam system, Range from 5G-14G, only need change the complete needle bed, easy and friendly operating
(6) Fully safety protect with front and back cover, anti-dust and protect the operator
(7) Fine Stitch quality and Stitch no changes even Voltage Shrinking, Even stitch quality from start needle to End needle for each course
Specification:
| Features | SHD-838F1 Fully Auto collar knitting machine |
| Gauge | 5g/7g/12g/ 14g/16g |
| Knitting width | 52" 68" 80 " |
| Speed | 1.2m/s |
| Knitting carriage | Single carriage |
| Yarn feeder | 6 yarn feeder |
| Racking | 2 needles adjustable |
| Power | Single Phase Ac 220v 50 hz |
| Stitch correction | Motor stitch by program |
| Needle type | Universal high / low butt needle with select butt |
| Measurement |
2150*800*1850 mm(52") 2550*800*1850mm (68") 2850*800*1850mm (80") |
Compact carriage with Multi-Gauge Cam System
Stably & Even stitch quality control by motor
6 Yarn feeder on 3 rail guide
Carriage Instant stop Or Return
Friendly Control And Program panel
Fully Operating and Max. 8 pattern In Memory
Knit can start from any Courses
Alarm In case of Error & information displayed
Pieces Counter, test function and more available
Apply for Plain & Semi Jacquard pattern
