100 Watt 6 Bands High Power Outdoor waterproof Prison Jammer ,Mobile Phone 2G 3G 4G GPS WIFI Jammer Up to 150m
$1.00 /Piece
Product Details
Transaction Comments
Outdoor High power mobile phone signal jammers 6-Band for Prison project, output power 100W jamming up 150m is able to disable all mobile phone frequencies CDMA GSM, 2G, 3G, 4G Lte, 4G Winamx ,Also is middle RF power drone jammer model, can defend 100% drones UAVs, like phantom 4, phantom 3 Professional, advanced, standard series, inspire series, block remote control signal 2.4, 5.8GHz, GPS L1 L2 L3 L4 L5, 433, RC 868 and 912MHz, jamming range 100-300 meters.
Basic specifications:
Jam signal type:
1: mobile phone 3G/2G GSM CDMA DCS 4G LTE + WIFI-2.4G signals
2: mobile phone 3G/2G GSM CDMA DCS 4G LTE +GPSL1 signals
3: Drone UAVS RC2.4G+RC5.8G+GPSL1L2L5+RC433 868 912 MHz
Output power: total 100W, 10-30W each band
Jam radius: 50-150 meters (GPS signal for 300m)
Power supply: 110-240V AC to 27V DC
Cooling system: high efficiency aluminum alloy radiator+ 5x cooling fans
Working time: not-stop working
Product size: 520x 340 x200mm
Product weight: approx 25kg (for panel directional antennas)
Package contents: jammer host x 1, antenna x6 or 6x 2 meter 1/2 cable for Omni-antennas .
Advantages:
★Output power total 100W, you can choose high gain 5-7dBi Omni or panel directional antennas, shielding 50-300m, still depends on the strength signal in given area
★Each unit can jam up to 6 frequency bands simultaneously, each frequency band is separate and with adjustable power from max to off (0), LED indicator lights display power supply
★100% safe VSWR over protection (isolator) for each modular
★Big aluminum alloy shell and cooling fans, not-stop to work
★Design for outdoor installation, secure design to avoid sabotage
★Additional option: wireless RC or Ethernet PC remote control
★100% Safe VSWR over protection for each modular
| Key Technical specifications : | |||
| Channel | Output Port | Frequency range | Average out-putting power |
| 1 | CDMA or GSM | 851-894 or 925-960MHz | 43dBm/20W |
| 2 | DCS/PCS | 1805-1990MHz | 40dBm/10W |
| 3 | 3G | 2110-2170MHz | 40dBm/10W |
| 4 | 4GLTE | 700-803 or 790-862MHz | 43dBm/20W |
| 5 | 4G WIMAX | 2500-2690 or 2300-2400MHz | 40dBm/10W |
| 6 | WIFI 2.4G | 2345-2500 MHz | 40dBm/10W |
| Power supply: AC adapter 50 to 60Hz, (110 or 240V AC to 27V DC) | |||
| Dimensions: 520x340x 200mm | |||
|
Packing size: 70*27*47cm Net weight: 22kg Gross weight: 25kg (use panel directional antennas) |
|||
|
Total power: 80W Shielding radius: (50-150) meters at -75dBm Still depends on the strength signal in given area Shielding radius of VHF/UHF signal should be lesser than cell phone signal |
|||
| Warranty: one year from delivery date | |||
|
OMNI FRP antenna: Dimensions: 500x 30x30mm Net weight: 0.5kg Gains: 5-10dBi VSWR >1.5 H: 180º V: 20 º |
|||
|
Panel directional antenna: Dimensions: 21x18x5cm Net weight: 0.5kg Gains: 5-10dBi VSWR >1.5 H: 60-90º V: 20-30º |
|||
|
Basic station directional antenna: Dimensions: 125x25x8.5cm Net weight: 10kg Gains: 12-20dBi VSWR >1.5 H: 60-90º V: 20-30º |
|||
| Key Technical specifications : | |||
| Channel | Output Port | Frequency range | Average out-putting power |
| 1 | CDMA or GSM | 851-894 or 925-960MHz | 43dBm/20W |
| 2 | DCS/PCS | 1805-1990MHz | 40dBm/10W |
| 3 | 3G | 2110-2170MHz | 40dBm/10W |
| 4 | 4GLTE | 700-803 or 790-862MHz | 43dBm/20W |
| 5 | 4G WIMAX | 2500-2690 or 2300-2400MHz | 40dBm/10W |
| 6 | GPSL1 | 1570-1610MHz | 40dBm/10W |
| Power supply: AC adapter 50 to 60Hz, (110 or 240V AC to 27V DC) | |||
| Dimensions: 520x340x 200mm | |||
|
Packing size: 70*27*47cm Net weight: 22kg Gross weight: 25kg (use panel directional antennas) |
|||
|
Total power: 80W Shielding radius: (50-150) meters at -75dBm Still depends on the strength signal in given area Shielding radius of VHF/UHF signal should be lesser than cell phone signal |
|||
| Warranty: one year from delivery date | |||
|
OMNI FRP antenna: Dimensions: 500x 30x30mm Net weight: 0.5kg Gains: 5-10dBi VSWR >1.5 H: 180º V: 20 º |
|||
|
Panel directional antenna: Dimensions: 21x18x5cm Net weight: 0.5kg Gains: 5-10dBi VSWR >1.5 H: 60-90º V: 20-30º |
|||
|
Basic station directional antenna: Dimensions: 125x25x8.5cm Net weight: 10kg Gains: 12-20dBi VSWR >1.5 H: 60-90º V: 20-30º |
|||
| Key Technical specifications : | |||
| Channel | Output Port | Frequency range | Average out-putting power |
| 1 | RC2.4G | 2400-2500MHz | 44.5dbm /30W |
| 2 | RC 868 ,912 and 916 Or 433 | 868-916 or 433MHz | 43dbm /20W |
| 3 | RC433 | 433 MHz | 43dbm /20W |
| 4 | RC5.8G | 5725-5850MHz | 40dbm /10W |
| 5 | GPSL2+L5 | 1170-1280MHz | 40dbm /10W |
| 6 | GPSL1 +GlonassL1 | 1560-1620 MHz | 40dbm /10W |
| Power supply: AC adapter 50 to 60Hz, (110 or 240V AC to 27V DC) | |||
| Dimensions: 520x340x 200mm | |||
|
Packing size: 70*27*47cm Net weight: 22kg Gross weight: 25kg (use panel directional antennas) |
|||
|
Total power: 100W Shielding radius: (300-500) meters at -75dBm Still depends on the strength signal in given area Shielding radius of VHF/UHF signal should be lesser than cell phone signal |
|||
| Warranty: one year from delivery date | |||
|
OMNI FRP antenna: Dimensions: 500x 30x30mm Net weight: 0.5kg Gains: 5-10dBi VSWR >1.5 H: 180º V: 20 º |
|||
|
Panel directional antenna: Dimensions: 21x18x5cm Net weight: 0.5kg Gains: 5-10dBi VSWR >1.5 H: 60-90º V: 20-30º |
|||
|
Basic station directional antenna: Dimensions: 125x25x8.5cm Net weight: 10kg Gains: 12-20dBi VSWR >1.5 H: 60-90º V: 20-30º |
|||
OEM customized service:
Frequency range can be customized: 4GLTE Wimax, Wi-Fi 2.4G, 5.8G, 3.6GHz, GPSL1-L5
Silkscreen OEM service can be offered
Applications:
o Can be applied at meeting rooms, conference rooms, museums, galleries, theatres, concert halls, churches, temples, restaurants, classrooms, training centers, factories, banks, trains, bus, places that require silence, confidentiality and information security
o For some locations of special purpose such as hospitals, gas stations, do field test first to make sure no interference happened to the normal operation of their equipment and instrument
