Day old chicks transported vehicle is also called baby chick truck, young chicks transported truck. There are several electronic ventilator fans on the top, and the left-right sides with several slidable windows to keep air ventilated. There is cooling reefer, adjusted the temperature freely, suitable for transporting farm poultry, etc.
There are ventilation and heating system inside the farm poultry transported truck. There are several electronic ventilator fans (according to the length of the insulation van) on the top for ventilating, assuring offering enough oxygen for the baby young chicks/ducks/ gooses in the van. There are several windows (according to the length of the chick box body) for ventilating, heating, oxygen-offering.
Hot sale FOTON
AUMARK day old chicks transported vehicle adopts FOTON LHD 4*2 original
chassis, 3800mm wheelbase, 6 manual speed transmission, 8.25R16 tyres*6+1,FOTON AUMARK 1995mm width
single row driver cab with power steering, 2.5ton front axle, 6tons rear axle,
, YC4D130-33 yuchai 130hp diesel engine,
etc.
2, FOTON AUMARK baby chick transported truck is with the overall dimension
(L*W*H): 6995×2230×3100 (mm), chick van body dimension (L*W*H): 5100×1940×1860 (mm).
If you're interested in our day old chick transported truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of FOTON AUMARK day old chicks transported vehicle is as below.
Main parameters of FOTON AUMARK day old chick transported truck chassis
|
Product name |
Foton aumark LHD 4*2 day old chick transported truck |
||
|
Overall dimension(L*W*H)(mm) |
6995×2230×3100 |
Chick van box dimension(L*W*H)mm |
5100×1940×1860 (mm). |
|
Drive type |
4*2 LHD, RHD is selective |
Total mass |
8495 |
|
Gearbox |
6 speed gear box |
Tyre specification |
8.25R16 rail tyres *6+1 |
|
Power steering |
Yes |
Driver cab |
Foton aumark 1995mm single row driver cab |
|
Engine |
YC4D130-33 yuchai 130hp diesel engine |
Emission standard |
Euro 3 |
Main technical parameters of day old chick van body
|
Performance and consumption |
|||
|
Heating system |
Watering system |
Without, client choose to install |
|
|
Cooling system |
One refrigerated reefer |
China made high quality vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab) |
|
|
Ventilation system |
Air duct installed on the floor for air flow |
Two/three lines |
|
|
Cold air ducts on the two sides of the van body |
Two cold air ducts for the refrigerated reefer |
||
|
Blind windows |
4 sets of
blind windows for the left and right van sides (as the pictures show); 2 sets
of blind windows for the front van plate. |
||
|
electronic ventilator fans |
1, 4 sets of
electronic ventilator fans with sliding doors for the rear plate door; 4 sets
of electronic ventilator fans for the van top |
||
|
Sky-window |
Top mounted sky windows*2 Sky-windows: 2*1=2 |
||
|
Dimension |
|||
|
Chick van box body |
Length |
5100mm |
|
|
Width |
1940mm |
||
|
Height |
1860mm |
||
|
Refrigerated van box |
Exterior and
interior with FRP( fiber reinforced plastic), and the middle with
80mm PU slices; |
||
