Waterproof Membrane Production Line
$560000.00 /set
Product Details
Transaction Comments
Basic Info
- Model NO.: BF-GXLQ-1200
- Condition: New
- Automatic Grade: Automatic
- Transmission Method: Pneumatic
- Thickness: 1.5-2mm
- Guarantee Period: 12 Months
- Speed: 5-60m/Min
- Capacity: 3-15million/Year
- Length: 7.5-10m/Roll
- Transport Package: Seaworthy
- Origin: China(Mainland)
- Certification: CE, ISO
- Customized: Customized
- Structure: Horizontal
- After-Sale Service: Provided
- Material: Modified Bituminous
- Parts: Indoor Part / Outdoor Part
- Standard Width: 1000mm
- Control System: PLC
- Trademark: Benefit
- Specification: 48*12*6m
- HS Code: 8474802000
Product Description
Product Line part
External production line
1) Environmental protection device is new equipment which independent research and
development by our company. There are three components, including spray system, electric tar
precipitator and photocatalytic oxidation equipment. The device can effectively filter dust, reduce
particulate emissions and remove odor.The indicators meet the national emission requirements.
2)The Department of feeding (oxidation) is automatic powder storage, which use spiral automatic
feeding method. The machine can be automatically Weighing, which is measurement accuracy. The
entire feeding process is no leakage, no pollution and it is high-speed fast.
3)The heating department uses the biomass heat conduction oil stove, which possess the character
of heat large, the energy utilization ratio is high and energy conservation environmental protection.
working principle
The whole working principle can be divided into 3 steps.
1.To mix the bitumen,rubber powder , talcum powder , engine oil and some other raw materials via
mixing tanks(the mixing tank should be kept warm by conduction oil).The finished mixtures can be
called bituminous mixtures .
2.The bituminous mixtures will be deliveryed into coating pools.Then the base material
(reinforcement)will be coated with the bituminous mixtures.At last ,the coated
reinforcement will be covered by PE film or sand or other materials.At that time ,the bitumen
membrane preliminary forming.
3.The finished products will be cooled by water and air,then be rolled by auto-winder.
Technical Parameter
There are two methods in application:
(a)One way is by heating and melting method.Heat the polyethylene film of the membrane and roof
deck surface by heating and melting method to be nearly melted (not flowing),then install the
membrane filly bonded to the roof deck with overlaps of 5-10cm.
(b)The other way is by cold adhesive method.Pour the cold adhesive homogeneously on the roof
deck, then roll the membrane to install it to be fully sticked to roof deck.
(c)After application,a full serious inspection is required to sure no air bubble,no falling away.etc.
to guarantee the waterproof life.
Company information
Changzhou Benefit Waterproof Equipment Co.,Ltd,established in 1990, is a professional
manufacturer which is specialized in researching, producing, marketing and service waterproof
equipment. As a private-owned enterprise,Our company is a famous supplier in the line
of waterproof equipment in China, also an important supplier in the international markets. On the
basis of absorbing foreign advanced science and technology, our factory has developed various
kinds of advanced waterproof equipment plants, and has got many national patents.The factory is
strictly in accordance with international quality system to ensure product quality. Our factory
pursues the enterprise culture of sincere, realistic and innovation, adheres to the service goal of
honesty, customer-oriented and win-win situation. We are looking forward to cooperating with you.
Frequently Asked Questions
Q1:How to get the sample?
A :We can provide you samples for quality inspection.According to our company policy, samples are free,
we only charge the freight fee.The freight fee will be returned If you place the order.
Q2:What's are the MOQ?
A :The MOQ is 500 square meters usually.Also we can according to your condition to set the MOQ.
Q3:How about the delivery time?
A :Delivery time about 15days after your deposit or L/C at sight.
Q4:What kind of payment do you support?
A :T/T, L/C and Paypal are accepted.
Q5:What's your main market?
A :Our products are exported to Southeast Asia,The middle East,West Europe,Africa,Australia and etc.
Q6:Can we visit your factory to inspect the goods for the order?
A :Welcome to visit our factory to inspect the quality.We sincerely hope to establish a win
win cooperation relationship with you.
Contact Details
- Roll unfolding device
- Intermediate feed device
- Reinforcement connecting device
- Reinforcement drying device
- Auto rectifying device
- Impregnation tension control device
- Asphalt coating device
- Sand-scattering device
- Sand-lifting device
- Filming and thickness-measuring device
- Sand-pressing with suspending device
- Cooling and embossing device
- Finished products storage device
- Traction-spring device
- Auto winder device
- Electrical operating control device
- Mixing-weighing system device
- horizontal storage tanks
- Powder-conveying system
- Smoke purification device
External production line
1) Environmental protection device is new equipment which independent research and
development by our company. There are three components, including spray system, electric tar
precipitator and photocatalytic oxidation equipment. The device can effectively filter dust, reduce
particulate emissions and remove odor.The indicators meet the national emission requirements.
2)The Department of feeding (oxidation) is automatic powder storage, which use spiral automatic
feeding method. The machine can be automatically Weighing, which is measurement accuracy. The
entire feeding process is no leakage, no pollution and it is high-speed fast.
3)The heating department uses the biomass heat conduction oil stove, which possess the character
of heat large, the energy utilization ratio is high and energy conservation environmental protection.
working principle
The whole working principle can be divided into 3 steps.
1.To mix the bitumen,rubber powder , talcum powder , engine oil and some other raw materials via
mixing tanks(the mixing tank should be kept warm by conduction oil).The finished mixtures can be
called bituminous mixtures .
2.The bituminous mixtures will be deliveryed into coating pools.Then the base material
(reinforcement)will be coated with the bituminous mixtures.At last ,the coated
reinforcement will be covered by PE film or sand or other materials.At that time ,the bitumen
membrane preliminary forming.
3.The finished products will be cooled by water and air,then be rolled by auto-winder.
Technical Parameter
| ITEM | APP/SBS Modified Bitumen Membrane Production Line Technical Parameters |
||||
| Capacity ,m2/year | For 3mmthick products ,the annual output of various modified bitumen waterproofing membrane can be 10 millions sqm per year ,with 250 annual manufacturing days per year ,2 working shifts per day and 8 hour working time per shift |
||||
| Width | 1000mm | ||||
| Reinforcement | Polyester mat ,fiberglass, compound | ||||
| Modified materials | SBS,APP,Rubber powder | ||||
| Facing materials | Self-adhesive ,Silver sand ,Slate flakes ,PE film ,Aluminum foil ,etc | ||||
| Linear speed | 5-60m/min(adjustable) | ||||
There are two methods in application:
(a)One way is by heating and melting method.Heat the polyethylene film of the membrane and roof
deck surface by heating and melting method to be nearly melted (not flowing),then install the
membrane filly bonded to the roof deck with overlaps of 5-10cm.
(b)The other way is by cold adhesive method.Pour the cold adhesive homogeneously on the roof
deck, then roll the membrane to install it to be fully sticked to roof deck.
(c)After application,a full serious inspection is required to sure no air bubble,no falling away.etc.
to guarantee the waterproof life.
Company information
Changzhou Benefit Waterproof Equipment Co.,Ltd,established in 1990, is a professional
manufacturer which is specialized in researching, producing, marketing and service waterproof
equipment. As a private-owned enterprise,Our company is a famous supplier in the line
of waterproof equipment in China, also an important supplier in the international markets. On the
basis of absorbing foreign advanced science and technology, our factory has developed various
kinds of advanced waterproof equipment plants, and has got many national patents.The factory is
strictly in accordance with international quality system to ensure product quality. Our factory
pursues the enterprise culture of sincere, realistic and innovation, adheres to the service goal of
honesty, customer-oriented and win-win situation. We are looking forward to cooperating with you.
Frequently Asked Questions
Q1:How to get the sample?
A :We can provide you samples for quality inspection.According to our company policy, samples are free,
we only charge the freight fee.The freight fee will be returned If you place the order.
Q2:What's are the MOQ?
A :The MOQ is 500 square meters usually.Also we can according to your condition to set the MOQ.
Q3:How about the delivery time?
A :Delivery time about 15days after your deposit or L/C at sight.
Q4:What kind of payment do you support?
A :T/T, L/C and Paypal are accepted.
Q5:What's your main market?
A :Our products are exported to Southeast Asia,The middle East,West Europe,Africa,Australia and etc.
Q6:Can we visit your factory to inspect the goods for the order?
A :Welcome to visit our factory to inspect the quality.We sincerely hope to establish a win
win cooperation relationship with you.
Contact Details
