Pump introduction:
SCP Series Stainless steel sanitary centrifugal pumps is made from stainless steel material according to food hygiene requirements and widely used to transfer milk ,drinks etc and other similar colloid liquid food and the temperature of liquid food is not higher than 100 degree Celsius.
SCP Series sanitary stainless steel centrifugal umps are simple, easy to dismantle, with adjustable-feet, shock-proof, little noise, high efficiency, long time running and soft material handling.
Pump material: SS304, SS316L etc
Mechanical seal type;
Single mechanical seal
Double mechanical seal
Dry grinding type mechanical seal
Voltage:
220-240v/380v-420v ,50 /60HZ
440v-460v,460v/490v, 50/60HZ
Specification Sheet:
|
Model |
Capacity |
Head |
Pump inlet/outlet（mm） |
Motor power |
|
(m3/h) |
（m） |
（kW） |
||
|
SCP-1 |
1 |
15 |
32/25 |
0.55 |
|
SCP-3 |
3 |
18 |
38/32 |
0.75 |
|
SCP-5 |
5 |
24/32 |
38/38 |
1.5 |
|
SCP-10 |
10 |
24/36 |
51/38 |
2.2 |
|
SCP-15 |
15 |
32/42 |
51/51 |
3 |
|
SCP-20 |
20 |
36/42 |
51/51 |
4 |
|
SCP-30 |
30 |
36/45 |
63/51 |
5.5 |
|
SCP-40 |
40 |
36/45 |
63/51 |
7.5 |
|
SCP-50 |
50 |
36/50 |
76/63 |
11 |
|
SCP-60 |
60 |
40/60 |
76/76 |
15 |
|
SCP-80 |
80 |
40/65 |
76/76 |
18.5 |
|
SCP-100 |
100 |
40/65 |
89/89 |
22 |
|
SCP-120 |
120 |
40/65 |
102/89 |
30 |
|
SCP-150 |
150 |
40/65 |
102/102 |
37 |
