1.Description
The automatic discharge fryer can save labor and is suitable for various industries, and can fry a variety of foods, such as meat patties, coated peanuts, spring rolls, fried pork rinds, green beans, sweet potato chips, etc.
2.Detail Introduce
1)The gas-type frying pan is divided into two types: oil-water separation and pure oil type. The internal heating structure is divided into two types: tubular type and direct-burning bottom type.
2)The fryer is equipped with automatic discharge system, automatic temperature control system, and the control system adopts touch screen control.
3. Advantage
1)Special heating structure design, full combustion, high thermal energy utilization rate and fast heating rate.
2)Automatic temperature control system, precise temperature control, to ensure product quality.
3)High degree of automation and labor saving.
4)A variety of heating methods can be selected, including electric heating, natural gas heating, liquefied gas heating, and diesel heating.
4.Application
Mainly used in restaurants, hotels, school canteens, small fried food plus enterprises, etc.
5. Parameter
Model No. |
Oil Capacity |
Power |
Frying Frame Size |
Equipment Size |
Weight |
DBS-F800 |
130L |
36kw |
800*600*350mm |
1300*1000*1400mm |
100kg |
DBS-F1000 |
220L |
48kw |
1000*800*350mm |
1500*1100*1400mm |
200kg |
DBS-F1200 |
330L |
60kw |
1200*1000*350mm |
1700*1400*1400mm |
220kg |
DBS-F1500 |
540L |
72kw |
1500*1000*350mm |
2000*1400*1400mm |
300kg |
