LPGP-65 LPG multistage pump is a centrifugal side channel pump with a horizontal structure, a total of 6 stages, the shaft is mechanically sealed, no cooling. LPGP-65 multistage pump is used to transfer LPG, especially for liquids with high pressure difference, low cavitation NPSH and gas content up to 50 percent, such as LPG pumped from underground tanks. The pump USES a pre-compressed turbine at the suction end, which makes it suitable for use in the case of low cavitation NPSH allowance. positive suction heads is lower than 0.5 m. Therefore, the pump can be used in bad air suction conditions. Application: 1. Bottling 2. Pump liquefied gas from underground tanks; 3. Load and unload large quantities of gas-filled tanker cars, tanker cars; 4. Liquefied gas pump gas recovery
Technical Parameter:
Max. Capacity: 42 m3/h
Max. Discharge. Pressure: 40 bar
Max. Viscosity: 100 cSt
Temperature Range: -40 to 220 degree celsius
| Model | LPGP-65 | LPGP-150 |
| Medium | LPG |
|
| Working temperature | -32 to 60 degree celsius | |
| Inlet/outlet diameter | DN65/DN40 | DN40/DN25 |
| Motor | 380V,50HZ/4KW/1450RPM | 380V,50HZ,5.5kw/1450rpm |
| Number of stages | 6 | 6 |
| Connecting flanges | DIN 2501 PN40 | DIN 2501 PN40 |
