CHL light type horizontal multistage centrifugal pumps are manufactured with repair free mechanical seals and the flow components are made of stainless steel (304 or 316).The pump has low noise, light corrosion resistance, beautiful appearance, small size, light weight and long service life etc features.
Application:
CHL horizontal multistage stainless steel centrifugal pumps are widely used for domestic central air-conditioning circulation and industrial liquid transfer Such as demineralized water, soft water, purification system, light oil circulation and pressurization etc.
small central air conditioning circulation
cooling system, chiller system.
industrial cleaning
water treatment (water purification)
aquaculture
fertilization/metering system
environmental application
CHL horizontal multistage centrifugal stainless steel pump is used to transfer the
thin, dry, non-condensing, non-explosive liquids without solid particles or fibers.
Liquid temperature &room temperature 15 to 70 DegC
Hot water operated 70 to 110 DegC
Maximum environment temperature: 40 DegC
Maximum operating pressure: 10 bar
Maximum inlet pressure is subject to maximum operating pressure
Ph: 4 to 9
Motor:
Fully enclosed, air cooled two poles motors
Protection class: IP55
Insulation class: F
Voltage:
1Phase, 220V to 240V,50HZ,2900RPM
3Phase, 220V to 240V, 50HZ,2900RPM
3Phase, 380V to 415V, 50HZ,2900RPM
1Phase, 220V to 240V, 60HZ,3500RPM
3Phase, 220V to 240V, 60HZ,3500RPM
3Phase,380V to 415V, 60HZ,3500RPM
