- Model NO.: FD25T-HWA3
- Power: Gasoline Engine
- Fuel: Diesel
- Lift height: 3000~5000mm
- Trademark: HECHA
- Origin: China
- Type: Gasoline/LPG
- Load Capacity: 1T - 5T
- Load center: 500mm
- Condition: New
- Specification: CEISO9001: 2008GOST
- HS Code: 8427209000
2.5 ton LPG&GASOLINE forklift with Japan Nissan engine
1.Product show
2. Product Description of 2.5 LPG&Gasoline forklift
| H2007 series 2.0-3.5T Gasoline/LPG Forklift specification | |||||||
| General | 1 | Model | FGL25T | ||||
| 2 | Power type | Gasoline/LPG | |||||
| 3 | Rated capacity | kg | 2500 | ||||
| 4 | Load center | mm | 500 | ||||
| 5 | Operator type | Seated | |||||
| 6 | Tyre type | Front/Rear | Pneumatic | ||||
| 7 | Number of wheels(X=driven)) | Front/Rear | 2 X /2 | ||||
| Dimensions | 8 | Lifting height | mm | 3000 | |||
| 9 | Free lift height | mm | 140 | ||||
| 10 | Fork size | LxWxT | mm | 1070x122x40 | |||
| 11 | Mast tilt range | F/R | 6/12 | ||||
| 12 | Overall Length(Without fork) | mm | 2583 | ||||
| 13 | Overall width | mm | 1150 | ||||
| 14 | Mast lowered height | mm | 1995 | ||||
| 15 | Mast extended height | mm | 4030 | ||||
| 16 | Overhead guard height | mm | 2070 | ||||
| 17 | Turning radius(Outside) | mm | 2240 | ||||
| 18 | Fork overhang(Wheel center to fork face) | mm | 483 | ||||
| 19 | Min.right angle stacking aisle width (Add load length and clearance) | mm | 2710 | ||||
| 20 | Wheelbase | mm | 1600 | ||||
| 21 | Tread | Front | mm | 970 | |||
| 22 | Rear | mm | 970 | ||||
| 23 | Ground clearance | Lowest | mm | 110 | |||
| 24 | Wheel base center | mm | 115 | ||||
| Performance | 25 | Speed | Travel | Full load | km/h | 17 | |
| 26 | No load | km/h | 19.5 | ||||
| 27 | Lifting | Full load | mm/s | 570 | |||
| 28 | No load | mm/s | 600 | ||||
| 29 | Lowering | Full load | mm/s | 450 | |||
| 30 | No load | mm/s | 550 | ||||
| 31 | Max.Drawbar Pull | Full load/No load | kg | 1250/850 | 1650/850 | ||
| 32 | |||||||
| 33 | Max.Gradeability | Full load/No load | % | 17/18 | 18/19 | ||
| Weight | 34 | Self weight | kg | 3680 | |||
| 35 | Wheel distribution | Full load | Front | kg | 5480 | ||
| 36 | Rear | kg | 700 | ||||
| 37 | No load | Front | kg | 1465 | |||
| 38 | Rear | kg | 2215 | ||||
| Wheels | 39 | Tyres | Spec | Front | 7.00-12-12PR | ||
| 40 | Rear | 6.00-9-10PR | |||||
| Brake | 41 | Brake type | Driving brake | Hydraulic | |||
| 42 | Parking brake | Mechanical hand brake | |||||
| 43 | Battery | Voltage/Capacity | V/AH | 12/100 | |||
| 44 | Transmission | Model type | Powershift (Manual) | ||||
| 45 | Stage | FWD/RVS | 1/1 (2/2) | ||||
| 46 | Operating pressure | Mpa | 17.5 | ||||
| 47 | Fuel tank capacity | L | 70 | ||||
All Hecha forklifts come with:
- comlpete set of working lights
- buzzer
- reverse alarm light
- mirrors
- seat belt
- complete set of maintanance tools
Options:
- Side shift
- Buit-in forkpositioner + side shift
- Paper clamps / brick clamps
- Cushion tires
- Double front tires
- Extra hydrolic valves
- Full free lift triplex mast
- Lifting heights up to 6000 mm
- Extra LPG tanks
3.After sevice
1) We provide excellent after service:
Our company consists of sales department after sale service department, dealer customer
relationship center, finance department and administrate department to offer you a wonderful
service.
2) We guarantee the quality and free repalcement, our warranty period is 12 month,within 12 months if you have any quality problems, except for electrical parts, because they are easily damaged if mis-installation.
3) If you have any questions, pls feel free to contact us, we are always here to help you.
Company show
↓
Production Line
Heli forklift co., ltd. Is a dedicated forklift maker in China. It is located in Jiaxing city, Zhejiang Province, P.R China. With the area of about 80.000 square meters and the advanced product line, the company has totally invested 20million US dollars. With 11,000sqm modern assembling hall, the designed production capacity is 20000 units of forklifts per year.
Heli Forklift Co., Ltd insists on the philosophy "Quality First, Customers supreme" and targets to be the most professional and excellent player in China forklift industry. Branded "HECHA", the forklifts are very popular with its high performance, comfortable operation, good looking and reliable working. The company will continuously keep its advantages with strict QC system.
The product range we have covered is 1.0-7.0Ton Internal Combustion Forklift, 1.0-3.0Ton 4wheeler Battery Forklift and 1.0-2.0ton 3pointer Battery Forklift. All the forklifts can be supplied with necessary attachments for different material handling application. The company will continuously strengthen the research force and enlarge the range of the products to meet the different demand of domestic and overseas customers.
What we are pursuing is to supply the best forklifts with best service. Welcome to join HECHA!
